UPS EMERGENCY POWER SUPPLY EASY BVS 800VA

To properly select the power of the device, it is recommended to consult a specialist. The power must be tailored to the power of the consumers and the type of load:

• the rated power of the device must be 20-30% higher than the power of the consumer with a resistive load (heaters, electric ovens, furnaces, stoves, incandescent lamps, etc.). This is necessary due to the high inrush current of the loads. When switching on the load and during repeated short-term operation modes, the load significantly exceeds for a short period the rated parameters specified in the technical specifications of the load;
• when the device is used in combination with consumers with an inductive load, the power must be 3 to 5 times greater than the power consumption of the load! (luminescent and fluorescent lighting, electric motors, pumps, air conditioners, refrigerators and freezers, etc.);
• when the device is used with consumers with a capacitive load, the selected power must be 5 to 10 times greater than the power consumption of the load! (switching chargers, LED drivers, switching power supplies, etc.).

If these instructions are not complied with, the device may be overloaded and cease functioning, and consequently the warranty will not cover the damage.
Specifications:

• Technical specifications of Uninterruptible Power Supply UPS BVS800I-GR, 230VAC, 450W, Line interactive, modified sine wave
• Brand: SCHNEIDER ELECTRIC
• Input voltage: 230 [VAC]
• Output power: 450 [W]
• Sine wave type: modified
• UPS type: line-interactive
• Battery capacity: 7Ah
• Overall dimensions: 305x161x93 [mm]
• Model: BVS800I-GR
• Output voltage: 230 [VAC]
• Plug socket type: Schuko
• Connector type: IEC C14
• Frequency range: 45~65 [Hz]
• Humidity range: 0~90 [%RH]
• Operating temperature: 0~40 [°C]
• Charging time: up to 90% in 8 hours
