Uni-T UT691-01 Visual Fault Locator

Uni-T UT691-01 Visual Fault Locator

by Uni-t
€19,90 - €19,90
€19,90
€19,90 - €19,90
€19,90
SKU DGT0453707
Ships within 7 business days Please note that quantities are limited and dynamic. At the time of ordering, the item may be out of stock. We will notify you in a timely manner in the event that we are unable to fulfill the order.

Избери период за изплащане и виж месечната вноска

Месечна вноска Обща сума за плащане ГПР Лихва Банка

Description

Uni-T UT691-01 visual fault locator

The Uni-T UT691-01 is a visual fault locator designed for detecting faults in optical fibers, identifying fibers, and performing maintenance work on optical installations. The device uses a red laser with a wavelength of 650 ±10 nm and offers both continuous and pulsed modes, which facilitates fault location and connection verification. An output power of at least 1 mW allows for operation with fiber optic sections ranging from 2 to 3 km in length, and the universal 2.5 mm FC connector ensures compatibility with popular fiber optic installations.

A person uses a fiber optic fault locator with a laser to check the continuity of an optical cable in a telecommunications cabinet.

Convenient operation during daily work

The device is equipped with a 3.7 V lithium-polymer battery with a capacity of 1050 mAh, which provides over 12 hours of operation on a single charge. A battery level indicator, a built-in LED flashlight, and an automatic shut-off function after 15 minutes enhance user comfort and help conserve energy. The non-slip housing, which meets the IP54 standard, and its ability to withstand drops from a height of 1 meter make the locator well-suited for field work, while its compact dimensions of 130 × 38 × 27 mm and weight of 62 g make it easy to transport and store.

A fiber optic locator connected to an optical cable during the diagnosis and detection of fiber optic faults.

Included

  • Visual fault locator
  • User manual

Specifications

Manufacturer Uni-T
Model UT691-01
Product type Visual fault locator
Laser output power ≥1 mW
Testing range 2–3 km
Laser wavelength 650 ± 10 nm
Connector type Universal 2.5 mm (FC)
Laser operating modes Continuous, pulsed
Power supply 3.7 V / 1050 mAh lithium-polymer rechargeable battery
Operating time >12 h
Battery status indicator 4 blue LEDs
Charging voltage and current DC 5 V / <1 A
Auto-off timer 15 min (manually adjustable)
Warning features Visual symbols, audio warnings
Button durability test 5000 cycles
Drop resistance 1 m
Protection rating IP54
LED flashlight Yes
Color Red and gray
Dimensions 130 × 38 × 27 mm
Weight 62 g
Certifications CE, UKCA
