Uni-T UT262E Non-Contact Phase Sequence Detector

Uni-T UT262E Non-Contact Phase Sequence Detector

by Uni-t
€86,90 - €86,90
€86,90
€86,90 - €86,90
€86,90
SKU DGT0453777
Ships within 7 business days Please note that quantities are limited and dynamic. At the time of ordering, the item may be out of stock. We will notify you in a timely manner in the event that we are unable to fulfill the order.

Избери период за изплащане и виж месечната вноска

Месечна вноска Обща сума за плащане ГПР Лихва Банка

Description

Uni-T UT262E Non-Contact Phase Sequence Detector

The UT262E is a non-contact phase detector in a clamp-on design, engineered for safe operation on three-phase systems without the need to touch exposed wires. This reduces the risk of electrical arcing and minimizes the danger of electric shock during field work. The device allows for quick verification of phase presence, identification of phase sequence, detection of phase loss, and localization of wire breaks, utilizing both audible and visual signals. It is ideal for service work, motor installation, and electrical system maintenance.

A hand holding a UNI-T phase detector connected with colored alligator clips to thick cables in a distribution cabinet.

Included

  • Phase sequence detector
  • 2 AA batteries
  • Carrying case
  • User manual
  • Warranty card
  • Inspection certificate



Specifications

Manufacturer Uni-T
Model UT262E
Type Non-contact phase sequence detector
Measurement method Non-contact (inductive clamps)
Voltage range 70~1000V AC
Operating frequency 45~66 Hz
Functions Phase detection / phase loss / phase sequence / open circuit detection
Cable diameter Ø2~40 mm
Cable length 0.6 m
Signaling LED + buzzer
Signal volume 65~70 dB
Auto-off After approx. 5 minutes
Operating time Over 20 hours
Safety class CAT III 1000V / CAT IV 600V
Protection rating IP52
Power supply 2 × AA 1.5V
Weight 237.7 g (with batteries)
Dimensions 88 × 30 × 66 mm
Certifications CE, UKCA
