| Marketing description |
| The NETGEAR M4250-9G1F-PoE+ switch is designed to meet business requirements, offering advanced features and efficient performance. With a switching capacity of 20 Gbps and support for up to 4093 VLANs, it is suitable for handling high volumes of traffic and complex network configurations. Security is a priority, with SSL 3.0 and TLS 1.2 ensuring that data remains secure during transmission. The switch also provides a total PoE budget of 110 W, allowing direct power delivery to connected devices and simplifying the network infrastructure. Its fanless design ensures quiet operation, making it ideal for noise-sensitive environments. Whether for a small business or a large enterprise, the NETGEAR M4250-9G1F-PoE+ offers the flexibility, security and performance needed to maintain a dynamic and efficient network. |
| Product features |
-
Robust security
With support for SSL 3.0 and TLS 1.2, the NETGEAR M4250-9G1F-PoE+ provides secure network communications, protecting data from unauthorised access.
-
Efficient performance
With a switching capacity of 20 Gbps and a throughput of 14.88 Mpps, this switch is designed to handle high volumes of traffic, ensuring efficient data flow across the network.
-
Advanced network features
Equipped with advanced Layer 3 switching, VLAN support for up to 4093 VLANs and comprehensive routing protocols, including IGMP, PIM and RIP, the NETGEAR M4250-9G1F-PoE+ is capable of supporting complex network architectures.
-
Enhanced connectivity
This switch offers a variety of ports, including 8 PoE+ ports, a Gigabit SFP port and USB-C for console management, providing flexible connection options for a wide range of devices.
-
Efficient power management
With a total PoE budget of 110 W, the NETGEAR M4250-9G1F-PoE+ delivers power to connected devices such as VoIP phones, IP cameras and wireless access points, reducing the need for additional power supplies.
|
| General |
| Device type |
Switch - 10 ports - L3 - Managed |
| Chassis type |
Side-to-side airflow, rack-mountable |
| Subtype |
Gigabit Ethernet |
| Ports |
8 x 10/100/1000 (8 PoE+) + 1 x 10/100/1000 + 1 x Gigabit SFP |
| Power over Ethernet (PoE) |
PoE+ |
| PoE budget |
110 W |
| Performance |
Switching capacity: 20 Gbps
Throughput (packet size 64-byte): 14.88 Mpps
Latency (1 Gbps): < 2.27 µs |
| Capacity |
Supported VLANs: 4093
ARP entries: 4000
Multicast entries (IPv4): 512
Multicast entries (IPv6): 128
Jumbo frame size: up to 12000
IGMP multicast groups: 2000
MSTP instances: 16
PVST instances: 32 |
| MAC address table size |
16K entries |
| Jumbo frame support |
12KB |
| Routing protocol |
IGMP, IGMPv2, IGMPv3, MLDv2, static routing IPv4, static routing IPv6, RIP, PIM-SM, PIM-DM, PIM-SSM |
| Remote management protocol |
HTTPS, CLI, Telnet, SSH, SNMP, RADIUS, TACACS+, RMON 1, RMON 2, RMON 9, RMON 3, SNMP 1, SNMP 2, SNMP 3 |
| Encryption algorithm |
TLS 1.2, SSL 3.0 |
| Features |
Support for IGMP, AVB, PoE timer, MIB support, RSPAN, LLDP-MED, policy-based routing, PTP, STP support, MTP, RSTP, BPDU, STRG, Root Guard, GVRP, GMRP, LACP support, DHCP snooping, DAI, IP source guard, DHCP relay, LLDP support, AAA, sFlow, PIM, MVRP, LACP, LAG, private VLAN, VLAN support, DHCP server, QoS, DoS attack prevention, 16MB packet buffer, fanless |
| Standards compliance |
IEEE 802.3at, IEEE 802.3af, IEEE 802.1ak, IEEE 802.1as, IEEE 802.1Qat, IEEE 802.1Qav, IEEE 802.3az, IEEE 802.1AX, IEEE 802.1ab (LLDP), IEEE 802.3ad (LACP) |
| Processor |
X ARM A9: 1.25 GHz |
| RAM |
2 GB |
| Flash memory |
256 MB |
| Expansion / Connectivity |
| Interfaces |
9 x 10/100/1000 Base-T RJ-45 8 ports (PoE+)
1 x 10GBase-X SFP
1 x management (Gigabit LAN) RJ-45
1 x console RJ-45
1 x USB Type A
1 x console (USB) Type C |
| Power |
| Power supply |
External power adapter |
| Installed quantity |
1 |
| Miscellaneous |
| Included accessories |
Mounting brackets, rubber feet kit, 2 x SFP slot covers |
| Included cables |
USB-C to USB-A cable |
| Rack mounting kit |
Included |
| Compliance standards |
FCC CFR47 Part 15 B Class A, ANSI C63.4:2014, ISED, ICES-003:2016 No. 7 Class A, EN 55032:2015 Class A, EN 61000-3-2:2014 Class A, EN 61000-3-3:2013, EN 55024:2010, EN 55035:2017, AS/NZS CISPR32:2015 Class A, CCC, GB/T9254-2008 Class A, VCCI-CISPR 32:2016 Class A, KC, KN32 Class A, KN35 Class A, EAC, IEC 62311, GOST 30804.3.2-2013, GOST 30804.3.3-2013, GOST 30805.22-2013, GOST CISPR 24-2013, BSMI, CNS 13438 Class A, IEC 62368-1 Second edition, IEC 60950-1 Second edition, CB, CSA, RCM |
| Localization |
Europe |
| Dimensions and weight |
| Width |
21 cm |
| Depth |
14 cm |
| Height |
4 cm |
| Weight |
965 g |
| Manufacturer warranty |
| Service and support |
Limited warranty - lifetime |
| Environmental parameters |
| Minimum operating temperature |
0 °C |
| Maximum operating temperature |
45 °C |
| Operating humidity range |
90% (non-condensing) |
| Minimum storage temperature |
-20 °C |
| Maximum storage temperature |
70 °C |
| Storage humidity range |
95% (non-condensing) |
