FAULT CURRENT PROTECTION 4P 40A 30MA AC ABB

ABB's four-pole residual current device with a rated current of 40A and 30mA sensitivity is designed to detect and interrupt earth leakage currents, providing reliable protection against electric shock and fire caused by current leakages.

Specifications:

Residual current type: Type AC
Rated short-circuit making capacity (Ics): 1 kA
Maximum surge current: 0.25 kA
Leakage current type: AC
Electrical Endurance: 10000 cycles
Mechanical endurance: 20000 cycles
Number of poles: 4P
Number of modular spacings on DIN rail: 4
Operating characteristic: Instantaneous
Neutral terminals position: Right
Rated cross-section:
4 - Flexible 10...25 mm²
1 - Rigid 25...25 mm²
Rated voltage (Ur): 230/400 V
Rated operational voltage: 230 … 400 V AC
Rated insulation voltage (Ui): 500 V
Rated impulse withstand voltage (Uimp): 4 kV
Rated current (In): 40 A
Rated residual current: 30 mA
Rated conditional short-circuit current (Inc): 6 kA
Rated frequency (f): 50 Hz
Power Loss: at rated operating conditions per pole 1.3 W
Number of modules: 4
Material compliance:
RoHS Declaration: EU Declaration of Conformity_FH200
RoHS Information: Pursuant to EU Directive 2011/65/EU and Amendment 2015/863 of July 22, 2019
RoHS Date: 20211115
REACH Declaration: Reach Declaration - ABB S.p.A. Vittuone
REACH Information: True - contains substances > 0.1 mass percentage
REACH Date: 20240429
Conflict Minerals Reporting Template (CMRT): Conflict Minerals Reporting Template
SCIP: 719d39e9-c62c-4c41-a6dc-53de2a11e8ea Italy
WEEE Category: 5. Small equipment (no external dimensions more than 50 cm)
WEEE B2C / B2B:
Ambient air temperature:
Operation -5 ... +40 °C
Storage -40 ... +70 °C
Degree of protection: IP2X
Dimensions:
Width in Number of Modular Spacings: 4
Net product width: 70 mm
Net product height: 85 mm
Net product depth/length: 69 mm
Net product weight: 380 g
Built-in depth (t2): 69 mm
